- Model: K8CC10BE
- Cooling capacity: 10,000 BTU/hr
- Voltage: 115/1
- Cooling Area (ft²): 333
- Refrigerant: R-32
Koldwave Modular Multi Air conditioner feature multi-function spot cooler providing various accessories available to fit customer needs. This Unit is used to spot cooling for large areas where cooling of the entire area is not practical or possible. A dedicated spot cooling thermostat controls the unit in this application. This Unit can also be used in smaller areas for room cooling. A control panel provides ease of use and contains a self-diagnostic function and display, showing operating modes, room and set temperatures, and faults, If an abnormal operation occurs, a visual display of the fault is shown.
- View more of our Koldwave Air Cooled Portable Air Conditioners
- Spot Cool/RoomCool Thermostat Settings
- Internally Insulated with Fiberglass Insulation
- Thermostatic Control with Multi-Speed Fan
- Separate Direct Drive Fan Motors
- R-32 Refrigerant
- Approx. Cooling Area 269 sq. ft (25m²)
- Optional Directional Nozzle (1)
- Self-Diagnostic System
- Off Timer
- Washable Filters
- Humidity Control Function
- 115V/1 Phase/60 Hz
- Includes Built-in Condensate Pump
- Auto/Manual Fan Speed Option
- 15 Amp Breaker
Safety Devices
- Compressor overload protector
- Anti-freezing thermister
- Automatic restart (Power interruption)
- Compressor time delay program
- High pressure switch
- Model: K8CC10BE
- Cooling Capacity (BTU/hr): 10,000
- Power Supply (Voltage): Single Phase, 115V, 60Hz
- Power Consumption (W): 950
- Rated Current (A): 8.49
- EER Btu/Wh: 10.5
- Nema Plug: 5-15P
- Power Cord Guage (AWG): 14
- Power Cord Length (ft.): 10
- No. of Cool Air Outlets Pcs: 1
- Condensate tank Gallons(Liters): Auto Pump Included
- Ambient Temperature Range (°F): 64 - 113
- Setting Temperature (Room Cool Mode) (°F): 64 - 86
- Setting Temperature (Spot Cool Mode) (°F): 32 - 86
- Application Area (Room Cool Mode) (ft²): 256.4
- Refrigerant Type: R-32
- Design Pressure - Hi/Low Psig: 460 / 250
- Indoor Air Flow (High/Low) (CFM): 320 / 220
- Wheels pcs / diameter: 4 / 76.2 mm
- Hot Air Duct Diameter In. (mm): 6 (150)
- Maximum Duct Length ft (m): 10 (3)
Dimensional Data
- Product (Width x Depth x Height): 17.25" x 24" x 20.5"
- Weight (Net): 119 lbs.
- Shipping Dimensions (Width x Depth x Height): 28" x 21.5" x 26"
- Shipping Weight: 143 lbs.
- Free phone technical support
- 2-year parts-only warranty
- 3-year compressor warranty
